TYPE-C Conductive Container Bag

TYPE-C conductive container bag

In accordance with the International Electrotechnical Commission IEC 61340-4-4 standard

TYPE-C Conductive container bag/Anti-static container bag/Release static electricity into the ground through conductive wires and conduction wires.

Product Introduction:

Size: 105X105X120cm (can be customized according to requirements)

The height of inlet and outlet and ring can be customized according to customer equipment

Applicable products:

Used to transport flammable powders, this product can avoid electrostatic ignition when flammable solvents or gases are present around the container bag.

Do not use:

Do not use this product when the conductive wire is not connected to the ground or is damaged.

Type-c TYPE conductive container bag, also known as ground type flexible container bag. It's made of a completely conductive material. Now the grounded C-type flexible container bag is more woven in the non-conductive polypropylene fabric interspersed into the conductive blend fabric material. This conductive braid material must ensure that all conductive wires are connected as one, and when using Type-C TYPE container bags, the black conductive film of the bag body must be connected with the ground wire, through the ground conduction, effectively remove the static electricity generated during loading and unloading, and prevent the occurrence of dangerous situations such as ignition and dust explosion.

Product features:

The design of this product takes into account that the ultra-fine powder will be sprayed out of the pinhole, so the anti-leakage sliver and non-woven anti-leakage are added. Besides, considering that the length and width of the product are too large to be transported on the truck side by side, the tension rib is added to solve the expansion problem. Considering the poor fluidity of the customer's loading materials, we suggest using the mesh tension sheet as the tension rib. All the above problems have been solved to avoid the difficulty of material entering the inside of the Angle bar. Allow customers to install, use worry-free.
